DESCRIPTION:

Coil Hook

C-Hooks are designed to handle coils in the eye horizontal position and are available in a wide range of capacities, coil sizes, and design styles. C-Hooks are custom designed per application.

30 Ton Capacity Coil Hook with urethane facing and custom finish

Product Features:

• High tensile strength alloy steel plate minimizes physical size.
• Counter balanced to hang level when empty.
• Inside radius on hooks avoid coil edge contact.
• Curved coil support on lower arm is standard.
• Guide handles for ease of coil positioning.
• Handles a wide range of coil widths.

Product Options:

• Replaceable urethane facing available for additional coil protection.
• Recessed counterweight for close stacking.
• Long carrying arm style for multiple slit coils.
• High temperature environment capability.
• Storage stand

For Quote:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Telescoping Coil Grab

This rack and pinion style grab allows for handling of a wide range of coil sizes with minimum manpower. Optional motorized rotation allows the crane operator to spot the coil with precise positioning. Coil grabs are custom designed per application.

Model 285- Telescoping Coil Grab shown

Product Features:

• Low headroom design.
• Lockout switch in carrying foot to prevent inadvertent opening.
• Replaceable wear plates.
• Hinged covers.
• Heavy duty worm gear reducer.
• Drive protection includes slip clutch.
• Machined slide arms.
• Curved supports on lifting feet for coil protection.
• Designed for easy maintenance.
• AC power.

For Quote:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

This rack and pinion style lifter allows for handling of a wide range of sheets and plates with minimum manpower. Lifters are custom designed per application.

30 ton capacity model 260 with special grab shoes shown lifting sheets

Product Features:

• Low headroom design.
• Replaceable wear plates.
• Heavy duty worm gear reducers.
• Drive protection includes slip clutch.
• Machined slide arms.
• Designed for ease of maintenance.
• AC power.

Product Options:

• Powered rotation with or without stops.
• Heavy duty function indicator lights.
• Integral weighing system.
• Maximum open/minimum closed limit switches.
• Carrying angles with dunnage cutouts (pictured above).
• Detachable, auxiliary carrying angles for handling longer loads.
• Chain or cable reel mounted end hooks for thin gauge or extra wide material.
• DC power.
• Electrical reversing motor controls.
• High temperature environment capability.

For Quote:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Parallelogram Sheet Lifter

The motorized Parallelogram Leg Drive Sheet Lifter is ideal where space between sheet stacks in storage is limited. This style lifter is designed so that the weight of the stacks of sheets or plates keeps the lifter closed. Optional motorized rotation allows the crane operator to spot the stack with precise positioning. Lifters are custom designed per application.

This 25 ton lifter was assembled and tested on-site at a facility in Indiana by our experienced team.

PRODUCT FEATURES:

• Narrow aisle space design.
• All pivot points equipped with hardened steel bushings and pins equipped for lubrication.
• Heavy duty worm gear reducer.
• Drive protect includes slip clutch.
• Electrical controls include stall relay.
• Designed for ease of maintenance.
• AC power.

PRODUCT OPTIONS:

• Powered rotation with or without stops.
• Heavy duty function indicator lights.
• Integral weighing system.
• Maximum open/minimum closed limit switches.
• Carrying angles with dunnage cutouts.
• Chain or cable reel mounted end hooks for extra wide or thin gauge material.
• DC power.
• High temperature environment capability.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Vacuum Lifting Beam

These Vacuum Lifting Beams are designed to handle large sheets or plates of metal in the primary metal industry as well as various other industries. Designed to your material weight and size requirements. Units can be operated with a pendant, crane mounted controls, or radio controls. Lifting beams are custom designed per application.

Custom designed Model 222 vacuum lifting beam with large square lifting pads that easily conform to loads

PRODUCT FEATURES:

• Trolley mounted crossarms for ease of adjustment.
• Vacuum pads and crossarms adjustable to handle a wide range of material sizes.
• Handles ferrous and non-ferrous material.
• Assures single sheet/plate handling.
• Minimizes product damage.
• Safety indicator lights.
• Vacuum reserve system to hold load during temporary power failure.
• Design assures quick attachment and release.
• AC power.

PRODUCT OPTIONS:

• Powered rotation for horizontal location.
• Durable LED lights and gauges.
• Built in support stands.
• Low vacuum indicator warning system.
• DC power.
• High temperature environment capability up to 600 degrees Fahrenheit.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Magnet Lifting Beam

This telescoping, rack and pinion style beam allows for handling of a wide variation of product lengths. Lifting beams are custom designed per application.

Telescopic magnet lifting beam show in the minimum spread position

PRODUCT FEATURES:

• Heavy duty rack and pinion telescoping drive.
• Telescopes to handle varying lengths.
• Heavy duty gear reducer.
• Drive protection includes slip clutch.
• Designed for easy maintenance.
• Designed to accommodate your lifting magnets.
• AC power.

PRODUCT OPTIONS:

• Individual 90 degree rotation of magnets for wide loads.
• Parking stand.
• Non-telescopic units are also available.
• Supplied with lifting magnets.
• DC power.
• Electrical reversing motor controls.
• High temperature environment capability.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Heavy Duty C-Hook

Standard Model 82-10-48 shown

Model 82 Heavy Duty Coil Hook

PRODUCT FEATURES:

• Designed for heavy duty applications.
• High tensile alloy steel plate reduces physical size and weight.
• Counter balanced to hang level when empty.
• Inside radius on hooks avoid coil edge contact.
• Curved coil saddle is standard.
• Guide handles for ease of hook positioning.
• Handles a wide range of coil widths.
• Available with optional padding for additional coil protection.
• Complies with ASME standards.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

PRODUCT FEATURES:

• Recessed counterweight allows for close stacking of coils which maximizes floor space.
• Handles a wide range of coil widths.
• Designed for heavy duty application.
• High tensile alloy steel plate reduces physical size and weight.
• Counter balanced to hang level when empty.
• Inside radius on hooks avoid coil edge contact.
• Curved coil saddle is standard.
• Guide handle for ease of hook positioning.
• Available with optional padding for additional coil protection.
• Complies with ASME standards.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Double Leg Coil Lifter

Model 86-15-48 shown

PRODUCT FEATURES:

• Most economical of the two-sided coil lifters.
• Two-sided coil lifter requires less aisle space.
• Lifting hook width adjustment pin is easy to use.
• Hooks manufactured from high tensile alloy steel.
• Coil width adjustment indicators for easy hook placement.
• Optional coil protection available.
• Complies with ASME standards.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Rotating Crane Hooks

Motorized Rotating Crane Hooks make rotating loads on the crane hook easy for the operator. Each unit is custom designed per your requirements.

Model 250 – Crane Block

PRODUCT FEATURES:

• Sheave pin includes lubrication fittings.
• External lubrication on heavy duty thrust bearing.
• Heavy duty worm gear reducer.
• Bull gear and pinion final drive.
• Drive protection includes slip clutch.
• Designed for ease of maintenance.
• 360 degree continuous rotation.
• AC power.

PRODUCT OPTIONS:

• Pin bail type attachment.
• Clevis or lug instead of crane hook.
• Hook/drive disengagement.
• Continuous rotation with electrical collector ring to operate motorized below-the-hook lifters.
• DC power.
• Mechanical stops.
• Electrical reversing motor controls.
• Integral weighing system.
• High temperature environment capability.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

PRODUCT FEATURES:

• Standard beam sizes.
• J-Hooks are custom cut per order to fit your specific application. (Provide Roll information at time of order.)
• Hooks can be fixed or pivot style.
• J-Hooks are infinitely adjustable between minimum & maximum spread.
• Complies with ASME standards.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

This C-Hook is the perfect solution when handling narrow or slit coils. The design of this lifter will hang level when loaded, unlevel when not loaded. A guide handle is provided to allow operator more control of the lifter.

Standard Model 82NC-1/2-12 shown

PRODUCT FEATURES:

• Handles narrow coils with less coil edge damage.
• More durable than web slings.
• Lightweight for easier handling.
• Built in guide handle for ease of coil positioning.
• Available with optional curved coil saddle.
• Inside radius on hooks avoid coil edge contact.
• Complies with ASME standards.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

PRODUCT FEATURES:

• Handles off center loads by adjusting the bail before a lift.
• Infinite adjustment of bail within range.
• Swivel hooks with hook latches standard.
• Wide range of sizes and capacities available.
• Complies with ASME standards.

PRODUCT OPTIONS:

• OPTION A – EXTRA HOLES– Allows for multiple hook positioning. Specify number and spread(s) required. *Could increase headroom.
• OPTION B – FASPINS– For ease of positioning hooks with quick release. Specify number of faspins required.
• OPTION C – EXTRA HOOKS – Allows for multiple pick points. Specify number of hooks required.
• MOTORIZED ADJUSTMENT – Please see our Posi-Leveler^™.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Adj. Lifting Beam

Model 17-2-6 shown

PRODUCT FEATURES:

• Bail adjusts horizontally for lifting unbalanced loads.
• Provides clearance in low headroom applications.
• Spread adjusts in 6” increments along lifting beam.
• Shackles included.
• Optional swivel hooks available.
• Complies with ASME standards.

PRODUCT OPTIONS:

• OPTION S – Pair of swivel hooks

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Fixed Spread Lifting Beam

Model 19-1-6 shown

PRODUCT FEATURES:

• Provides clearance in low headroom applications.
• Eye hooks with hook latches standard.
• Fixed spread.
• Complies with ASME standards.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Coil Lifting C-Hooks

Heavy-Duty C-Hooks from Bradley Lifting are a simple and effective solution for your coil handling needs.

Bradley C-Hooks feature a frame cut from single, alloy steel plate and are designed for a 24/7 production environment.

C-Hooks are a perfect fit when you need to stack coils (or slit coils) closely together, end-to-end, or when access to the coil I.D. is restricted to one side. Additional features include urethane bumpers, low-headroom designs, and motorized rotation.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Telescoping Coil Grabs

Motorized Telescoping Coil Lifters are the preferred solution when handling coils where the axis is horizontal.
The telescoping legs offer the ability to handle a wide range of coil diameters and widths while maintaining a low headroom profile.

Motorized rotation about the vertical axis, hold-down arms for un-banded coils, and digital weighing systems are just a few of the many additional features available for these devices. Coil protection features, and built-in safety devices are also available and can be integrated with automated crane applications.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Parallelogram Coil Lifters

Parallel Linkage Coil Lifters are commonly used for coil handling applications where the coil axis is horizontal. The linkage mechanism is good for narrow aisles in coil storage areas but does require additional headroom to operate when compared to a telescoping drive lifter. Powered rotation, retractable feet, and a multitude of additional safety options are also available. Contact a Bradley Engineer to discuss whether a Parallel Linkage Coil Lifter is a fit for your application needs.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

For coils positioned with the axis vertical (“eye to the sky”) and the underside of the coil is not accessible, a vertical axis coil tong is an excellent solution. Heavy-duty units built for continuous operation, these tongs are custom-configured to handle your full range of coil sizes. Single-rim grip or double-rim grip versions are available, as well as single or double coil handling designs. Automatically activated tongs offer virtually “hands-free” operation.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Motorized Sheet Lifters provide the utmost efficiency and ease of use. When frequent handling is needed, or when access to the lifter is limited, a motorized lifter is the ultimate choice. Rugged and dependable, Bradley Motorized Sheet Lifters are a sure way to boost your productivity. Motorized Sheet Lifters can also be configured for manual use when a power supply is not available.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Motorized Sheet Lifters provide the utmost efficiency and ease of use. When frequent handling is needed, or when access to the lifter is limited, a motorized lifter is the ultimate choice. Rugged and dependable, Bradley Motorized Sheet Lifters are a sure way to boost your productivity. Motorized Sheet Lifters can also be configured for manual use when a power supply is not available.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

To meet customer requirements, Bradley Lifting engineers will often incorporate the ability to telescope (manual or motorized) and to rotate within the Multiple Pad Vacuum Lifter. Other factors that must be considered are temperature, porosity of the material and availability of vacuum or power sources on the crane.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Lifting Beams can be custom-configured to accommodate your existing magnets for handling anything from single plates to rows of billets or bundles. Bradley offers fixed beam or manually adjustable and motorized adjustable designs to suit any lifting application. These rugged beams are designed to handle the heavy shock loads typical of magnet handling applications and can also be pre-wired to provide plug-and-play functionality.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

J- Hook Lifting Beams are an excellent solution for handling of Rolls, Shafts, and other Round materials. The hook spacing, radius, and length can all be customized to suit your needs. Fixed hooks and manual or motorized adjustable hooks are also available

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Bradley has a wealth of experience in Work Roll handling. Whether you need to lift a single or double work roll set, with chocks or without, we have a solution for you! Bradley offers all types of heavy-duty work roll handing equipment suited for the Roll Shop or the Mill Aisle. Lifting Beams, simple mechanical devices, and motorized grabs are just some of the many choices.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Backup Roll Handling is one of the most demanding applications in the rolling mill. The sheer size and weight of these units presents a challenge for any crane operator. Bradley has developed many custom approaches to handling the Backup Rolls, each as unique as the designs of the Mills that they work in. From automatic mechanical lifters, to fully motorized grabs, chances are we’ve got a design to suit your needs.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

In the Roll Shop, handling of the Roll Chocks is often cumbersome once removed from the work roll set. Bradley has many options to improve safety and efficiency of handling these components. Contact a Bradley Engineer to discuss your lifting application.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Just like the chocks themselves, Bearings are also difficult to handle components of work roll sets. Often handled in the axis-vertical (eye-to-the-sky) orientation, Bradley has many dedicated devices to help make lifting of these components a much safer process. Call and talk to a Bradley Engineer to find out more!

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Drafto “C-Hooks” are designd and manufactured to AISE Specifications for Steel Mill Duty and Heavy Industry. Special C-Hooks are available for light duty applications.

C-Hook Features:

Internal and external replaceable padding or liners.

Perfectly balanced.

Made from alloy steel.

Replaceable bails.

Single, double and triple handling.

Wide range of capacities.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Drafto Corporation designs and manufactures rugged and reliable sheet and plate lifting devices.

Features include:

Parallelogram W/ Slider Spindle Construction.

Dual or Single Bail.

Optional Extensions.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

LAMINATED LADLE HOOKS

Drafto manufactures heavy duty laminated ladle hooks for hot metal applications.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

C-Hook Features of Bushman Equipment, Inc. Include:

• Unitized construction of a C-Hook means only the bail, counterweight and coil support saddle are welded to the main, one-piece burnout.
• Tapered lower carrying arm facilitates C-Hook entry into the coil ID.
• Beveled top edge on carrying arms is standard on C-hooks under 20,000 pound capacity.
• Coil support saddles are standard on C-Hooks with 20,000 pound or greater capacity.
• Each C-Hook is custom engineered to meet the customer’s specific requirements for load configuration, weight, lifting area and headroom.
• C-Hook Options
• High temperature
• Mill duty lifters
• Storage stands
• Protective pads
• Bail pins
• Motorized rotation
• Digital weighing systems
• Designs for narrow coils
• Remote control features
• C-Hook Applications
• Heavy Duty Material Handling
• Paper Roll Handling
• Slit Coil Handling
• Close stacking C-Hook
• Pivoting coil C-Hook

All Bushman Equipment, Inc. Heavy Duty C-Hooks are designed and manufactured in accordance with the latest revisions of ASME Specifications B30.20 and BTH-1, Design of Below-the-Hook Lifting Devices.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Bushman manufactures a complete line of coil grabs that have been engineered to meet a variety of dimensional, capacity and special application needs. Quality-built throughout, these lifters will provide years of continuous, safe and efficient coil handling.

Bushman manufactures coil grabs with heavy steel weldments. They feature: telescoping, motor-driven legs; formed, curved saddles on the lifting surfaces, and limit switch in the lifting pad to prevent accidental opening under load.

Optional features that enhance lifting efficiency and protect the coil include:

§ Motorized rotation. § Photo eyes to help position the grab on the center of the coil. § Limit switches at ends of leg travel. § Full length pads on all coil contact surfaces. § Rubber or steel toe and heal rollers in the lifting feet. § Built-in weigh scales with on-board or remote display.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Bushman manufactures a complete line of sheet and plate lifters engineered to meet a variety of dimensional, capacity and application requirements.

Bushman sheet lifters have many production applications and numerous optional features to customize the equipment to your individual needs.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Spreader beams lift loads with single or multiple attachment points. They handle a variety of loads such as long bundles, rolls, cylinders, and machinery.

Bushman designs spreader beams for safety, durability and simple operation. We have significant experience designing and building lifting and spreader beams for use in primary steel mills, steel service centers, pulp and paper mills, power plants and in difficult environments with varied crane layouts.

All Bushman spreader beams are designed and manufactured in accordance with the latest revision of ASME Spec. B30.20 and BTH-1: Design of Below-the-Hook Lifting Devices.

Five basic spreader beam models are available in many different design configurations.

§ Model 413 A spreader beam with formed hooks for use with slings. § Model 415 A spreader beam with plate hooks to engage a shaft or mandrel, used primarily for handling paper rolls. § Model 420 The positions of the hooks on this spreader beam are adjustable to accommodate different load lengths. § Model 439 A basic spreader beam with safety swivel hooks for use with slings or chains. § Model 490 A chlorine cylinder lifting beam. Units are in stock for immediate shipment.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Series “A” Cable Reel Features:

• Cast Aluminum Construction
• Slip Ring in Gasketed Enclosure
• Durable Baked Polyester Powder Painted Finish
• Unitized 20 Amp Slip Ring
• Easily Accessible Gasketed Junction Box
• Spool Configuration Prevents “Lock-out”
• Field Adjustable Cord Guide with Four Rollers
• Positive Locking Dog with Field Adjustable Disengage Feature
• Maintenance Free Enclosed Power Spring
• Type SO Cable Included On All Reels
• Field Adjustable Cord Stop

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Built tough to provide dependable Mill Duty service under adverse conditions. Specially designed to operate reliably and safely, MMD reels feature “beefed-up” all steel construction, oversized bearings on both sides of the load bearing spool, and a heavy duty shaft. Four spool diameters, a wide variety of drum diameters and either direct or geared drive allow maximum flexibility in specifying the right reel for your application. Models for 2 to 36 conductors, cable length from 30′ to 200′. May also be used for crane magnet applications.

Built tough to provide dependable Mill Duty service under adverse conditons

beefed-up all steel construction with baked polyester finish

oversized bearings on both sides of load bearing spool

heavy duty shaft

externally mounted Safetychange^® spring motors and NEMA-IV slip rings for simple, fast replacement

O-Ring seal provides watertight, dust-tight seal

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Safe-Lec 2 Conductor Bar

SAFE-LEC 2^® V-Contact Conductor Bar System – the new standard in overhead crane electrification. SL 2 is ideal for monorail and material handling system electrification as well.

Safe-Lec 2 provides these great benefits:

Positive Tracking – “V-contact” in the bar guides the shoe and provides continuous conductivity. Collector arms articulate in a wide range of motion to help keep the collector shoe in contact with the rail.

Safe Insulation – Conductor bar is insulated for IP2 “finger-safe” operation.

Bolted Splice – a postive connection that cannot pull apart over time.

Minimum Number of Unique Parts – same cover profile fits all bar styles!

Easy System Configuration – using our advanced “Quick Quote” software.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Current Capacity Range:

500 amps, 700 amps, 1000 amps, and 1500 amps, at 600 volts.

Maximum Running Speed:

2,000 feet/minute (609.6 meters/minute)

OPTIONS:

Heater wire systems (500 amp only)

Stainless steel hardware

Green bonding (ground) conductor covers, black “UV resistant” outdoor covers, and high-heat covers

Curved systems – Contact the Factory

DURA-COAT – For Corrosive Environments

Hevi-Bar II is available with our optional DURA-COAT finish. Dura-Coat is a specially formulated coating that combines a ceramic compound with an epoxy binder to provide superior corrosion resistance and adhesion to the base materials. The entire bar is coated except in the stainless steel collector shoe running area; the insulating cover is applied over the coating.

All metal parts of the collector arm are coated. Arms are not coated as they are made from high-strength glass filled polymer.

DURA-COAT is an ideal conductor bar for galvanizing and electro-plating lines, chemical plants, smelters, foundries and cast houses, coke and ore handling cranes, and oxidizing/electro-winning facilities.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Conductix-Wampfler Side Contact Conductor Bar is a variation of the 8-Bar system designed for lateral (side) entry of the collector. UL / CSA listed. Side Contact is ideal when there is insufficient room for standard “bottom entry” mounting and/orconductors must be more closely spaced than standard 8-Bar allows.

Current Capacity Range:

40 amps, 90 amps, 110 amps, 250 amps, and 350 amps

Maximum Running Speed:

900 feet/minute (274.3 meters/minute)

Factory installed covers are available in:

Rigid PVC: -10° F to 160° F (- 23.30° C to 71.10° C)

Medium Heat: – 25° F To 250° F (- 31.70° C to 121.10° C)

Side-Contact Conductor Bars:

Come with cover and connector pins installed. Copper and Laminate Bars also come with Joint Keepers.

Have expansion sections that are required for every 350 feet (106.7m) for 40, 90, and 110 amp systems, or 250 feet (76.2m) for 250 or 350 amps to compensate for thermal expansion.

Are easy to configure using our advanced “Quick Quote”software!

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Conductix-Wampfler is the world’s leading designer and manufacturer of Cable Festoon Systems. We offer a comprehensive range of Cable Festoon Systems to support, protect, and manage power/data cables or air/fluid hoses. Regardless of the particular cable or hose package, the running speed, indoors or out, Conductix-Wampfler has the appropriate system for the job. Cable Festoon Systems are particularly suitable for demanding environments, such as in mills and at port facilities. Our systems are ideal for overhead cranes, gantry cranes, water treatment systems, car wash systems, bulk material conveyors, plating lines, and many other types of moving equipment.

You can choose from a complete array of cable and festoon hardware, and accessories such as cable connectors, tow cable, tow webbing, cable organizers, junction boxes, and Push Button Pendants – Refer to Catalog CAT1001. Conductix-Wampfler specializes in custom engineered systems. If you don’t see exactly what you need, contact us with your requirements.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Conductor Systems

Bottom contact Figure 8 conductors from 90 to 350 amp.

Side contact Figure 8 conductors from 90 to 350 amp.

Heavy duty conductors in 500, 1000, and 1500 amp ratings with stainless steel running surface for longer wear and higher speed operation.

Applications & Services

Cover with ultra violet additive for outdoor sun locations.

High temperature cover (280F) for all Figure 8 and HD-500 conductors.

Stainless steel conductors in Figure 8 for corrosive atmospheres.

Epoxy coated, stainless steel, and insulated hangers for wet and corrosive atmospheres.

Factory built expansion sections and anchors for expansion control.

Factory bent curved conductor sections for Figure 8 systems.

Minimum bend radius is 30″

A variety of Figure 8 covers for matching competitive systems.

Heated conductor systems for ice prevention on outdoor systems or freezer storage.

Totally enclosed covers with flap for air-born contaminants, indoor & outdoor versions.

Bare conductors available for extreme heat applications.

Special long-wear collector brushes for Figure 8 systems.

Cleaning brushes for Figure 8 and HD conductors.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Conductor Systems

Bottom contact Figure 8 conductors from 90 to 350 amp.

Side contact Figure 8 conductors from 90 to 350 amp.

Heavy duty conductors in 500, 1000, and 1500 amp ratings with stainless steel running surface for longer wear and higher speed operation.

Applications & Services

Cover with ultra violet additive for outdoor sun locations.

High temperature cover (280F) for all Figure 8 and HD-500 conductors.

Stainless steel conductors in Figure 8 for corrosive atmospheres.

Epoxy coated, stainless steel, and insulated hangers for wet and corrosive atmospheres.

Factory built expansion sections and anchors for expansion control.

Factory bent curved conductor sections for Figure 8 systems.

Minimum bend radius is 30″

A variety of Figure 8 covers for matching competitive systems.

Heated conductor systems for ice prevention on outdoor systems or freezer storage.

Totally enclosed covers with flap for air-born contaminants, indoor & outdoor versions.

Bare conductors available for extreme heat applications.

Special long-wear collector brushes for Figure 8 systems.

Cleaning brushes for Figure 8 and HD conductors.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Conductor Systems

Bottom contact Figure 8 conductors from 90 to 350 amp.

Side contact Figure 8 conductors from 90 to 350 amp.

Heavy duty conductors in 500, 1000, and 1500 amp ratings with stainless steel running surface for longer wear and higher speed operation.

Applications & Services

Cover with ultra violet additive for outdoor sun locations.

High temperature cover (280F) for all Figure 8 and HD-500 conductors.

Stainless steel conductors in Figure 8 for corrosive atmospheres.

Epoxy coated, stainless steel, and insulated hangers for wet and corrosive atmospheres.

Factory built expansion sections and anchors for expansion control.

Factory bent curved conductor sections for Figure 8 systems.

Minimum bend radius is 30″

A variety of Figure 8 covers for matching competitive systems.

Heated conductor systems for ice prevention on outdoor systems or freezer storage.

Totally enclosed covers with flap for air-born contaminants, indoor & outdoor versions.

Bare conductors available for extreme heat applications.

Special long-wear collector brushes for Figure 8 systems.

Cleaning brushes for Figure 8 and HD conductors.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Conductor Systems

Bottom contact Figure 8 conductors from 90 to 350 amp.

Side contact Figure 8 conductors from 90 to 350 amp.

Heavy duty conductors in 500, 1000, and 1500 amp ratings with stainless steel running surface for longer wear and higher speed operation.

Applications & Services

Cover with ultra violet additive for outdoor sun locations.

High temperature cover (280F) for all Figure 8 and HD-500 conductors.

Stainless steel conductors in Figure 8 for corrosive atmospheres.

Epoxy coated, stainless steel, and insulated hangers for wet and corrosive atmospheres.

Factory built expansion sections and anchors for expansion control.

Factory bent curved conductor sections for Figure 8 systems.

Minimum bend radius is 30″

A variety of Figure 8 covers for matching competitive systems.

Heated conductor systems for ice prevention on outdoor systems or freezer storage.

Totally enclosed covers with flap for air-born contaminants, indoor & outdoor versions.

Bare conductors available for extreme heat applications.

Special long-wear collector brushes for Figure 8 systems.

Cleaning brushes for Figure 8 and HD conductors.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:
Open Conductor Systems

Wherever there are particularly harsh environmental influences, such as in coking plants and steel mills, we offer a safe and powerful power supply with our open conductor systems. You can easily supply your mobile applications (overhead travelling cranes, loading bridges, container handling equipment, monorails, coke-making machines, electric hoists, etc.) with current ratings of up to 3,000 A via the open conductor systems.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Increasing cycle times as well as reliability and flexibility are key features of success in advanced production. The advantages of contactless power supply are in the low wear and maintenance characteristics, insensitivity to contamination and unrestricted travel speed. Due to the high clock frequency, the highest system efficiencies and the smallest construction sizes can be achieved. It does not matter whether the conveyor system is designed as a automatic guided vehicle or as an electric monorail system.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Intelligent applications are increasingly used in smart factory and warehouse automation. In the complete supply chain, products need to be lifted, transported, rotated, and moved. All this can be realized with our mobile drive controllers vDRIVE. The modular design of our control systems allows uncomplicated integration into your system, as well as a short-term availability of spare parts.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Our long-standing proven system, worldwide in use and absolutely reliable – a true VAHLE classic. The modular VAHLE cable trolley (vFESTOON) is tailored to meet your individual needs: Whether round or flat cables or hoses, whether for electricity or data transport – with our cable trolley systems, many applications are possible, whether in port, steelwork or concrete plant.

The VAHLE cable trolleys are durable, the material has been able to withstand adverse environmental influences for years and reflects the VAHLE quality standards. You also have the option to get the cable trolley you have requested pre-assembled by our experienced staff. Our assembly team will gladly put your crane system into operation and bring you up to date with the latest technology

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

The Flex EX2 series of wireless controls offer even more features and greater performance than our first generation Flex EX radios at the same great value. These durable, rugged, and feature-rich radios are ideal for use in material handling, overhead crane, and industrial applications. Flex EX2 transmitters are ergonomic and lightweight, and are available in 4, 6, 8, and 12 button style options to meet all your application needs.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Our compact MLTX bellybox transmitter incorporates the latest polymer technology in a lightweight, comfortably contoured, yet durable case. It’s available with many options to meet the needs of a variety of applications and industries.

Comfortable and Lightweight
Ergonomically designed contoured case is more comfortable for the user

One of the lightest bellybox transmitter available today—50% lighter than our previous transmitters

Easy to use, angled lever controls enhance operator comfort

Rugged and Reliable
Rugged, super tough nylon made to withstand shock

Rated NEMA 4 (IP66), sealed to withstand harsh environments

Synthesized frequency generation enhances reliability

Dual access code system provides peace-of-mind, as the signal only operates the intended equipment

Designed to minimize power consumption, providing one of the longest life batteries in the industry today – rechargeable NiMH battery pack standard

Military grade auxiliary function switches

Versatile and Flexible
Choose up to 7 levers or 2 joysticks

Side mounted key switch and code plug

Choose up to 6 toggles; mushroom E-stop

Available stepless, 1, 2, 3, or 5 speeds in a non-detent lever or joystick

Backward compatible with most existing Telemotive systems

Up to 4 selectable licensed frequencies

Optional certification for use in hazardous locations requiring ISA 12.12.01 Class I and Class II, Division 2, Group A, B, C, D, E, F, and G

Synthesized RF technology available for:

-Unlicensed (FCC Part 15/RSS-210)
-Licensed (FCC Part 90/RSS-119)

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Our MLTX2 bellybox transmitter incorporates the latest electronic technology in a lightweight, comfortably contoured, yet durable case. It’s available with several customizable options to provide the ideal solution for a variety of applications and industries.

Comfortable and Practical Design
Ergonomically designed contoured case is more comfortable for the user

One of the lightest bellybox transmitters available today—50% lighter than other bellybox transmitters

Easy to use, angled lever or joystick controls enhance operator comfort

Choose up to 7 levers or 3 joysticks; up to 12 toggles; mushroom E-stop

Durable and Reliable
Rugged, super-tough nylon housing is made to withstand shock

Rated NEMA 4 (IP66), sealed to withstand harsh, industrial environments

Synthesized frequency generation enhances reliability

Access code system provides peace-of-mind, as the signal only operates the intended equipment

Designed to minimize power consumption, providing one of the longest life batteries in the industry today — rechargeable NiMH battery pack is optional

Versatile and Feature-Rich Options
Configure the MLTX2 on a Windows PC with the optional Radio Control Programmer (RCP) via USB or the USB/IR adapter

Easily upload new programming in the field with USB connection

Optional graphic display keeps the operator informed of system status at all times, and makes configuring access codes, channels, and other system setting simple

Two-way feedback available, showing maching related parameters, engine diagnostic information. Received Signal Strength Indication (RSSI), and much more

Several frequency options including 400MHz, 900MHz, and 2.4GHz

Backward compatible with most existing Telemotive systems

Synthesized RF technology available for:

Unlicensed (FCC Part 15/RSS-210)

Licensed (FCC Part 90/RSS-119)

Available with ATEX and IECEx approvals for Zone 0, Zone 1, and Zone 2 applications

ATEX Approval: II 1 G Ex ia IIC T3/T4 Ga

IECEx Approval: Ex ia IIC T3/T4 Ga

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Patriot

Patriot^™ is a high value three-motion, two-speed controller available in four standard systems that is used for wireless remote control of cranes.

Highlights

Three pre-defined systems with up to 15 functions

Rugged and reliable system with less downtime

IP 65 enclosure ensures durability from the elements

Battery life offers more than 130 hours of continuous operation

Can be configured with a RAC16 programmer, setting the system address and frequency

Ten-foot wiring harness out of receiver

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Remtron

CommandPro

CommandPro^™ is a durable, crane wireless remote control with up to 23 control functions and is available in three sizes.

Highlights

Three sizes with up to 23 control functions

Rugged and reliable system with less downtime

IP 65 enclosure offers protection from the elements

Battery life offers more than 130 hours of continuous operation

Can be configured with a RAC16 programmer, setting the system address and frequency

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Safe-T-Stop

Safe-T-Stop is an industrial grade wireless emergency stop solution that puts control in the hands of those in the best position to prevent injury to employees or damage to equipment.

Highlights

Large red Safe-T-Stop button

Up to seven functions possible

Can be used in operations that require UL913

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

T34/T36

Remtron lever-style bellybox remote controls are made with a heavy-duty aluminum housing that is ideal for the wireless remote control of cranes.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Remtron

T44/T46

The Remtron lever-style remote controllers (T44 and T46) come equipped with a wide selection of control options used for the wireless remote control of cranes.

Highlights

Durable, polymeric enclosure

Rugged and reliable system with less downtime

Battery life offers more than 350 hours of operation depending on battery configuration

Can be configured with a RAC16 programmer, setting the system address and frequency

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

The Remtron product line offers a variety of machine control units used for wireless remote control of cranes and machine control.

Highlights

Available with standard or customized functionality

Compatible with all Remtron^™ controllers

Can be configured with a RAC16 programmer, setting the system address and frequency

Rugged and compact NEMA 4, protection class, industrial enclosure

8 to 43 function relays plus analog (option), alarm and stop, compatible with contractor or VFD

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

The Advantage Series receiver utilizes a proprietary “PLC on a Chip” technology which allows for application specific ladder logic programming. The system is modular in design to provide both analog and digital input and output capabilities for various voltage and current conditions.

Features

Ease of Maintenance

Radio configuration: 450-470 MHz FCC Part 90 licensed

Unlicensed FCC Part 15 communication option available

Power, error/fault and digital I/O diagnostics indication

On-board watchdog safety circuitry

Proprietary radio protocol with Cyclical Redundancy Checking (CRC)

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Designed by our customers to meet today’s industrial demands. The L Series transmitters combine leading edge technology in an ergonomic design for easy operation and durability in the harshest environments.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

– Handheld transmitters ranging from 4 single-step buttons + STOP, up to 10 two-step buttons, with optional selector switches and radiomatic^® shock-off / roll-detect / zero-g safety features. radiomatic^® pilot offers inclination function and thumb joystick for precise proportional handheld control.

– Belly-box transmitters are available with multiple analog paddles or multiple multi-step or analog joystick controllers. LED, gray-scale or color feedback displays (including video) are possible on all transmitter types and all are powered by NIMH or Lithium-ion batteries.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Manufacturer of hand-held transmitters ranging from 4 single-step buttons, up to 10 two-step buttons, with optional selector switches & shock-off, roll-detect, zero-g safety features. Belly-box transmitters are available with multiple analog paddles or multiple multi-step or analog joystick controllers. LED, gray-scale or color feedback displays are possible on all transmitter types. Receivers are available from 8 black & white outputs to more than 100. Multiple analog & serial outputs are available.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Magnetek’s IMPULSE•VG+ Series 4 drives continue our tradition of providing the most reliable and cost-effective adjustable frequency crane controls available. With hundreds of thousands of drives in operation backed by decades of experience, IMPULSE drives are the smart choice.

IMPULSE drives are designed especially for material handling applications, providing a complete package of crane-specific capabilities far beyond a general purpose drive’s functionality. The IMPULSE•G+ Series 4 can be used as an open-loop vector or V/F crane control for traverse motions or mechanical load brake hoists.

Industry-leading safety and performance features combine with our superior application expertise to provide unmatched performance.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

Product Description

If you are upgrading your hoist motor controls with a Power Electronics^® VFD or Multi-Vector^® drive, consider enhancing your upgrade with a ready-to-go and pre-wired control panel to make your installation quick and easy!

Our Standard Hoist Control Panels Include:**

A Micro-Speed^® Variable Frequency Drive, a closed-loop Vector drive, or contactor motor controls

Panels available for all voltages: 208-230, 385-415, 460, and 575VAC; VFDs programmable for 50, 60, or 120 Hz

Standard Allen-Bradley control components, or optional other brands

NEMA Type 12 enclosures standard (sized per requirement)

Branch Fusing and Motor Thermal Overload Protection standard (designed to NEC specifications)

Braking contactors as required

Components mounted on a removable sub-panel

Panel wiring 105°C computer-generated labels on both ends

Common raised terminal strip to ease installation

Duct channels covering main wire runs

Factory inspected and fully tested

Regeneration resistors built-in or included, where applicable

Control panel wiring schematics, operations manuals, and Bill of Materials included

CDMA Duty A, B, C, D (standard); E, F, and Long Lift (L) available

UL/cUL labeling available

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

The Next Generation of Crane Performance

Magnetek’s IMPULSE•G+ Series 4 drives continue our tradition of providing the most reliable and cost-effective adjustable frequency crane controls available. With hundreds of thousands of drives in operation backed by decades of experience, IMPULSE drives are the smart choice.

IMPULSE drives are designed especially for material handling applications, providing a complete package of crane-specific capabilities far beyond a general purpose drive’s functionality. The IMPULSE•G+ Series 4 can be used as an open-loop vector or V/F crane control for traverse motions or mechanical load brake hoists.

Industry-leading safety and performance features combine with our superior application expertise to provide unmatched performance.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Product Description

The Micro-Speed^® Smart-Move^® series A.C. variable speed drives are your most cost-effective option for upgrading your motor speed controls (up to 3 HP). These miniaturized VFD’s are built with the high demands of crane/hoist systems in mind, but are perfect for any application where precision motor speed control and reliability is required. All 3-phase VAC’s available.

UL/cUL listed.

Universal Voltage Input models are available with 208-480VAC in the same unit – Why not stock a unit on each service truck to upgrade your customers? Universal VAC input makes it easy!

MSM-R models are perfect for traverse applications such as Bridge, Trolley, or Monorail use; the controlled ramp to stop deceleration will help save you time and money by virtually eliminating brake wear.

MSM-RH models are preset for use in hoists or other coast to stop applications (only for use with hoists that have a separate load brake, or self-locking worm drive hoists).

All Micro-Speed^® Smart-Move^® drives now include Version 2.2 updates, including I2T motor thermal protection and Auxiliary Inputs. The I2T protection feature removes the need to have separate motor overload relays in your control panel. Prior to Version 2.2, the Smart-Move^® MSM series did not have model numbers ending with the letter “R”. However, the Smart-Move^® Version 2.2 is a direct replacement of previous Smart-Move^®models (versions 2.1 and earlier).

For traverse applications, the Micro-Speed^® RP models are also available. These models can replace control panels with their built in 2-pole solid state AC brake control board (up to the drive’s rated line voltage). This eliminates the need for a separate brake contactor.

Micro-Speed^® Smart-Move^® drives have 3 isolated speed inputs, and are rated for temperatures up to 50° C. If more inputs are needed, the Micro-Speed^® CXR series allows for up to 5 speed inputs, as well as analog speed input. The CXR^™ series must also be used for motor sizes above 3 HP, or for applications with temperatures up to 60° C.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Protorq^™ Drives

Dedicated AC Drives eliminate the need for an external PLC where the program incorporates all the functions commonly required in crane applications.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

DESCRIPTION:

Protorq^™ Drives

Dedicated AC Drives eliminate the need for an external PLC where the program incorporates all the functions commonly required in bridge applications.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com

Product Description

The Micro-speed CXR^™ series A.C. variable speed drives are heavy-duty industrial VFDs with the highest current and temperature ratings in the industry. Built from the ground up with the demands of material handling in mind, they are perfect for Bridge Cranes, Trolleys and Monorails—or any other heavy duty application where precision motor speed control and safety is required.

UL/cUL listed.

CXR units are pre-programmed for traverse motions. The controlled ramp-to-stop deceleration will help save you time and money by virtually eliminating brake wear.

CXRH models are pre-programmed for use in hoists or other coast-to-stop applications (only for use with hoists that have a mechanical load brake, or self-locking worm drive hoists).

Both units will work with your existing controls (push buttons, consoles, radios, you name it!) with up to 7 isolated speed inputs—no extra input cards needed! The drives can also be programmed to allow for infinitely variable speed control with as few as two speed inputs.

All Micro-Speed^® CXR^™ drives now include Version 2.2 updates, featuring I2T motor thermal protection built into the drives. This removes the need to have separate motor overload relays in your control panel. Prior to Version 2.2, the Micro-Speed^® CX series did not have model numbers ending with the letter “R”. However, the Micro-Speed^® CXR^™ Version 2.2 is a direct replacement of all previous CX models (versions 2.1 and earlier).

For traverse applications, Micro-Speed CXRP (1-5 HP) models are also available. This version of the CX series has a built-in 2-pole solid-state single-phase AC brake control board (for use with brakes up to the drive’s line voltage rating). This eliminates the need for a separate brake contactor on the travel motion. CXRP^™ models are not for use in hoist applications.

For applications with smaller motors (up to 3 HP), the Micro-Speed Smart-Move series offers a smaller and more economical option. For applications with motors larger than 40 HP, and for more advanced programming options—including our exclusive Page-Swap^™ feature, see our Micro-Speed MX series.

For hoist applications without mechanical load brakes, see the Micro-Speed Multi-Vector “No Load Brake Hoists” drives – the MV series.

FOR QUOTE:

Call: 800-552-6720

Email: sales@tmcranes.com
